SM-HC MODULAR SCANNER SYSTEM (For use with DCM-1 and DCM-2)
FEATURES
The SM1-HC switches both reference and active signals at the same
time.
The SM2-HC is capable of switching currents at up to 50 Amps, a perfect partner for the DCM-2.
The SM-HC system can handle up to 256 channels, all controllable from PDsoft.
The SM2-HC is capable of switching currents at up to 50 Amps, a perfect partner for the DCM-2.
The SM-HC system can handle up to 256 channels, all controllable from PDsoft.
APPLICATIONS
For use with DCM-1 and DCM-2 DCPD units.
Monitoring of multiple specimens using one DCPD unit.
Monitoring multiple areas of interest on one specimen.
Monitoring of multiple specimens using one DCPD unit.
Monitoring multiple areas of interest on one specimen.
OVERVIEW
The scanner system provides a modular way of monitoring multiple specimens or areas of interest and
is designed for use in conjunction with the DCM-1 or DCM-2 series of crack growth monitors
manufactured by Matelect or indeed as a standalone scanner system.
The SM-HC system is modular and can be specified (or expanded) to cover a total of 256 specimen channels. Each module is based on a 4 channel switching unit. Two types of unit exist; the SM1-HC is used for switching the DCPD X and Y signals, whilst the SM2-HC is used to switch the DC excitation current. Both modules are under the control of a single Scan Controller unit, the SC1 or in the case of the DCM-2 a SC1 scan controller module built into the unit.
The SM-HC system is modular and can be specified (or expanded) to cover a total of 256 specimen channels. Each module is based on a 4 channel switching unit. Two types of unit exist; the SM1-HC is used for switching the DCPD X and Y signals, whilst the SM2-HC is used to switch the DC excitation current. Both modules are under the control of a single Scan Controller unit, the SC1 or in the case of the DCM-2 a SC1 scan controller module built into the unit.
